ESP8089 SoC

High Level of Integration

Measuring just 5mm x 5mm, ESP8089 requires minimal external circuitry and integrates antenna switches, RF balun, power amplifier, low noise receive amplifier, filters and power management modules - all in one tiny package.

High Performance & Low Interference

ESP8089 is a self-contained 2.4GHz 802.11 b/g/n Wi-Fi networking offload engine for application processors. It connects to the processor via the high-speed SPI/SDIO interface. ESP8089 also integrates adaptive radio biasing for low-power operation, advanced signal processing, spur cancellation and radio co-existence features for common cellular, Bluetooth, DDR, LVDS, LCD interference mitigation.

Dual Low Power Modes

By using an advanced power-management technology which implements power-down modes whenever necessary, ESP8089 consumes minimal power. The typical current consumption is less than 12uA in sleep mode, and less than 1.0mW (DTIM=3) or 0.5mW (DTIM=10) when staying connected.
